| Model | Voltage | Torque (kgf.cm) |
Torque (Lbf.in) |
Torque (N.m) |
Repeatable Torque Accuracy (%) |
Free Speed (r.p.m) |
Screw Size Dia (mm) Machine Screw |
Screw Size Dia (mm) Tapping Screw |
Weight (g) |
Length (mm) |
Bit Type |
| MYAC51-1512L | AC:110~120V | 1.5~12 | 1.33~10.44 | 0.15~1.18 | ±3% | 1200 | 1.6~3.0 | 1.6~2.6 | 470 | 245 | A、B、C、D |
| MYAC51-1512LF | AC:110~120V | 1.5~12 | 1.33~10.44 | 0.15~1.18 | ±3% | 2000 | 1.6~3.0 | 1.6~2.6 | 470 | 245 | A、B、C、D |
| MYAC51-0317LF | AC:110~120V | 3~17 | 2.57~14.78 | 0.29~1.67 | ±3% | 2000 | 1.6~3.5 | 1.6~3.0 | 470 | 245 | A、B、C、D |
| MYAC51-0422L | AC:110~120V | 4~22 | 3.52~19.12 | 0.39~2.16 | ±3% | 1200 | 2.3~4.0 | 2.3~3.5 | 470 | 245 | A、B、C、D |
| MYAC52-1512L | AC:220~240V | 1.5~12 | 1.33~10.44 | 0.15~1.18 | ±3% | 1200 | 1.6~3.0 | 1.6~2.6 | 470 | 245 | A、B、C、D |
| MYAC52-1512LF | AC:220~240V | 1.5~12 | 1.33~10.44 | 0.15~1.18 | ±3% | 2000 | 1.6~3.0 | 1.6~2.6 | 470 | 245 | A、B、C、D |
| MYAC52-0317LF | AC:220~240V | 3~17 | 2.57~14.78 | 0.29~1.67 | ±3% | 2000 | 1.6~3.5 | 1.6~3.0 | 470 | 245 | A、B、C、D |
| MYAC52-0422L | AC:220~240V | 4~22 | 3.52~19.12 | 0.39~2.16 | ±3% | 1200 | 2.3~4.0 | 2.3~3.5 | 470 | 245 | A、B、C、D |
