MYR(3) Series<br>(Lever Start) - MYTORQ Industrial Precision Torque Control Screwdriver

CATEGORY

Products / Brushless Auto Shut off Screwdriver

Features
Specifications
External Dimension
Torque Range Reference Chart
Accessoroes
Download

Features

Adopted brushless motor for clean, quiet, and accurate operation
The auto shut off clutch mechanism provides outstanding ±5% torque accuracy
The contactless micro switch increase lever lifespan to 10 million time
The durable clutch is made of high quality material, which can endure 2 million tightening
Ergonomic design for long timer operation

Specifications

Model	Torque (N.m) (Hard Joint)	Torque (N.m) (Soft Joint)	Repeatable Torque Accuracy (%)	Free Speed (r.p.m) HI	Free Speed (r.p.m) LO	Screw Size Dia (mm) Machine Screw	Screw Size Dia (mm) Tapping Screw	Weight (Kg)	Length (mm)	Power Controller	Bit Type
MYR-2050L	20~50	20~40	±5%	230		≤14	≤12	2.2	380	MYP40-1500	W1/2”

Applicable Bit Type

External Dimension

Torque Range Reference Chart

Accessories

MYP40-1500

KP-AUXA、AUX1

Spiral Cable

KL-2000

Download

MYR(2~3) Series Catalog

MYR-0206L / MYR-0309L / MYR-0412L / MYR-0412LF / MYR-0618L / MYR-0618LF / MYR-0825L / MYR-0825LF / MYR-1235L/ MYR-2050L/ MYR-0206P/ MYR-0309P/ MYR-0412P/ MYR-0412PF/ MYR-0618P/ MYR-0618PF/ MYR-0825P/ MYR-0825PF/ MYR-1235P/ MYR-2050P manual
