MY-TR5 - MYTORQ Industrial Precision Torque Control Screwdriver

CATEGORY

Products / Torque Readout Screwdriver

Features
Specifications
External Dimension
Torque Range Reference Chart
Accessoroes
Download

Features

4 digits and 7 Segment of torque display
24x4 LCM display settings
Password and key control to avoid operator adjusting settings.
Counting preference set up (count up and count down)
Slow start time 0.0-9.9 sec
Slow start speed (10%~90%,L1~L9)
Workpiece in position sensor (on/off)
Monitor fastening thread range
I/O signal (mos-relay)
RS-232 interface for data output, storage and use with barcode scanner
Save up to 99 programs
Monitor fastening time range
Monitor fastening torque range
Error code
Auto learning
Change torque unit
Offset setting
External start
External reverse
External disable tool
External confirm
Slot for SD memory card (Support 32GB and below)
Built-in power
Ethernet
Save up to 99 sequences

Specifications

Model	MY-TR5
Input Voltage	AC 100V ~ 240V
I/O Output Voltage	DC 24V 50mA／12V 100mA
Batch Count	1-99
Count method	Count-up／Count-down
Continued induction switch(sensor)	ON/OFF
Sensor switch mode	ON(2 Sensors)／OFF(1 Sensor)
Slow start time setting	0~9.9 seconds
Slow start speed setting	L0:100%,10%~90% L1~L9 Rated speed
Stop time detection	0.00~9.99 seconds
Torque value detection	0.0~550.0 kgf.cm
Screw thread detection	0.0~999.9
External signal input	Start / Reverse / Disable / Confirm / Cleared / Gate
External signal output	OK／NG／OK ALL／STOP
Serial interface	RS-232X2
Assembly management	MY-DAS／MY-AMS
External dimensions	185 x320x209(mm)
Weight	5.55KG
Accessories	Power cableX1 KeyX2
Applicable Models	MY2-TR MY5-TR MY7-TR MY8-TR MY9-TR MYR-TR MYLR-TR MYT-TR

External Dimension

Download

MY-TR5 Series Catalog

MY-TR5 manual
